Solar connector, Smarttrack04 Module-level Rapid Shutdown

CE IP67 waterproof 30A DC 1000V 2.5mm2 4mm2 6mm2 Solar PV Cable Panel Connector for solar pv system ...

(Hot selling index)
Wholesale price $

CE/ISO9001/IECSolar PV Cable Panel Connector for solar pv system.

  • 30 days easy returns
  • Order yours before 2.30pm for same day dispatch(Domestic supply only)
Introduction

Compatible with multiple types of modules.

Pre-installed before module delivery (04 RSD).

Simplified installation/maintenance, Customization acceptable.

Features :
  • Rated voltage: 1000V
  • Rated current: 20A
  • Body Material: PPO/PC
  • Contact Material: Copper,Tin plated
  • Degree Of Protection: IP2X/IP67
  • Temperature Range: -40℃～+125℃
  • Safety Class: II
  • Overvoltage Type/Pollution Degree: 6000V(50Hz, 1min)
Packing 500 pairs per carton
Single package size 4X3X2 cm
Contact Resistance Of Plug Connector CE/ISO9001/IEC
Contact Resistance Of Plug Connector CAT III/2
Port ShangHai,NingBo,ShenZhen
